High-performance draper platform for harvesting crops that are not at ground level
This platform represents an efficient option when the grains to be harvested are at a height of 7 cm or more from the ground by combining the features of the draper and the simplicity of a rigid cutting bar.
Cutting Length: 25, 30, 35, 37, 40, 42 and 45 feet
High resistance, to be applied to different harvester’s brands by means of an adapter with a hydraulic system that allows the angle of attack to be regulated from the cabin of the harvester.
Schumacher boxes and blades
DRAPER FEEDING SYSTEM
It has two draper strips in a transverse direction that work on a fixed structure and a central draper that operates in the direction of advance of the harvester. The delivery auger accompanies the material for correct feeding.
Mechanical System: Mechanical System composed of square boxes oil immersed gears and roller chains.
RIGID CUTTING BAR
High resistance spindle holder bar rigidly mounted to the header’s frame.
CARDAN TRANSMISSION OF BLADE CONTROL BOXES
It has a square gear box and an oscillating box on each side of the header linked to a cardan that includes a safeguard cover optimizing synchronization during operation.
In the rice harvest, the orbital reel is crucial for correct feeding in case of grain falling.
- The original Piersanti’s tines allow the operator to harvest all the material avoiding losses.
- The system allows the regulation of the angle of attack of the tines according to the type and conditions of the crop to be harvested.
- The reel operating speed is hydraulically calibrated from the cabin.
MAIN TRANSMISSION BY TIMING BELT
Brand: GATES POLYCHAIN® GT CARBON™, carbon fiber.
Cam reel for fallen crops equipped with steel tines.
Reinforced structure, built with pipes and profiles.
Fore carriage system, dual wheels, high resistance axles.
Bumpers with warning lights.
Rigid Draper DR-2000 Brochure
